| Tên thương hiệu: | GENY |
| Số mẫu: | YC1891G |
| MOQ: | 1 CÁI |
| giá bán: | Có thể đàm phán |
| Điều khoản thanh toán: | L/C,T/T,D/P |
| Khả năng cung cấp: | 100/năm |
| Power Supply | AC220 V ±10%, 50 Hz ±2 Hz |
|---|---|
| Ambient Temperature | -10°C to +40°C |
| Relative Humidity | 35% to 95% |
| Voltage Range | 24 V to 288 V |
|---|---|
| Max. Output Power | 10,800 VA |
| Voltage Setting Resolution | 0.01% |
| Voltage Stability | 0.02% / 50 ppm / 120 s |
| Load Regulation | 0.01% |
| Voltage Distortion | ≤ 0.3% (entire linear load range) |
| Current Range | 1 mA to 120 A (on request up to 230A) |
|---|---|
| Max. Output Power | 12,000 VA (MAX) |
| Current Setting Resolution | 0.01% |
| Current Stability | 0.02% / 50 ppm / 120 s |
| Continuous Current | 100 A |
| Load Regulation | 0.01% |
| 20-min Maximum Current | 120 A |
| Current Distortion | ≤ 0.3% (entire linear load range) |
| Phase Shift Range | 0° to 360° |
|---|---|
| Phase Resolution | 0.01° |
| Frequency Range | 45 Hz to 65 Hz |
|---|---|
| Frequency Resolution | 0.01 Hz |
